Negatoscopes ONIKO for radiography
Negatoscopes for radiography NR negatoscopes for radiography LED NRLED
ONIKO negatoscopes are applied to examine X-ray pictures (negatives) and any medical pictures, that are depicted on transparent films.
There are different models of negatoskopes for X-ray pictures viewing of any sizes.
The light fields are divided by scopes of 36x43 cm, which can be switched on separately.
Negatoscopes are switched on net 220 V, 50 Hz.
| Name | Light field size, cm | Scope number | Availability of intensity control | Brightness in the center of the field, cd/m2 | Dimensions L x W x H, mm | Power VA, more |
|---|---|---|---|---|---|---|
| NR-01, NRLED-01 | 36 x 43 | 1 | - | 4200 ±25% | 410x110x530 | 145 |
| NR-11, NRLED-11 | 36 x 43 | 1 | discrete 60%, 80%, 100% the maximum |
4200 ±25% | 410x110x530 | 180 |
| NR-02, NRLED-02 | 72 x 43 | 2 | - | 4200 ±25% | 800x110x530 | 290 |
| NR-12, NRLED-12 | 72 x 43 | 2 | discrete 60%, 80%, 100% the maximum |
4200 ±25% | 800x110x530 | 360 |
| NR-04, NRLED-04 | 144 x 43 | 4 | - | 4200 ±25% | 1500x110x530 | 600 |
| NR-14, NRLED-14 | 144 x 43 | 4 | discrete 60%, 80%, 100% the maximum |
4200 ±25% | 1500x110x530 | 615 |
